Elevator Braking Resistor RX20
RXG20 High-Power Corrugated Wire-Wound Braking Resistor for Variable Frequency Drives (400W/500W/800W, 50Ω)
Introduction
RX20 corrugated wirewound braking resistor for elevator inverter
Overview
| Specification Parameter | Details / Options |
| Model Number | RX20 |
| Rated Power | 100w/150w/200w/300w/400w/500w/600w/800w/1000w |
| Resistance Range | 10RJ/20RJ/30RJ/40RJ/50RJ/60RJ/75RJ/100RJ/150RJ |
Key Features
✅ Corrugated nickel-chromium alloy strip, excellent heat dissipation
✅ High alumina ceramic tube substrate, high temperature resistance & insulation
✅ Green high-temperature flame-retardant insulating coating, anti-oxidation
✅ Wide power range: 100W,150W,200W… up to 10KW
✅ Custom resistance value available
✅ Stable performance under large impulse current
✅ Easy installation with metal mounting brackets
✅ Replacement spare part for elevator maintenance & renovation
Material Composition
Resistance heating element: Nickel-chromium alloy strip
- Base skeleton: High alumina ceramic tube
- Surface coating: High temperature resistant green insulating paint
- Mounting bracket: Painted cold rolled steel
- Terminal: Tin-plated copper
Application
Elevator frequency converter dynamic braking
Servo motor load & discharge testing
Lift modernization & maintenance replacement parts
Industrial equipment energy consumption
